Features
- PFHC and DC-DC converter are consolidated in Full Brick size.
- High efficiency: 91%（PFE500SA-48）, 91%（PFE700SA）
- Wide baseplate temperature :-40 to +100°C (Exclusion PFE500SA-12)
- High power factor (95%), PFHC module (EN61000-3-2)
- Replacement support: External dimensions, mounting dimensions, and electrical specifications are compatible with existing series
Specifications (catalog download) (technical data download)
| PFE 300SA-12 |
PFE 300SA-28 |
PFE 300SA-48 |
PFE 500SA-12 |
PFE 500SA-28 |
PFE 500SA-48 |
PFE 700SA-48 |
|
| Input voltage range | 85 - 265VAC(Integrated harmonic current suppression function) | ||||||
| Output voltage | 12VDC | 28VDC | 48VDC | 12VDC | 28VDC | 48VDC | 51VDC |
| Output current | 25A | 10.8A | 6.3A | 33A | 18A | 10.5A | 14A |
| Effeciency (typ) | 84％/ 85％ | 86％/ 88％ | 87％/ 89％ | 84％/ 86％ | 87％ / 89％ | 89％ / 91％ | 89％/ 91％ |
| Power factor | 0.95 min | ||||||
| Cooling | Conduction cooling | ||||||
| Operating ambient temperature |
-40°C to +100°C (Baseplate temperature) |
-40°C to +85°C (Baseplate temperature) |
-40°C to +100°C (Baseplate temperature) |
||||
| Withstand voltage | Input - Baseplate : 2.5kVAC, Input - Output : 3.0kVAC for 1min Output - Baseplate : 1.5kVDC for 1min |
||||||
| Safety standard | Approved by UL60950-1, CSA60950-1, EN60950-1 | ||||||
| Functions | Over voltage, Over current, Thermal protection | ||||||
Product lineup
| Model name | Input voltage range |
Input current (typ) |
Nominal output voltage |
Max. output current |
Max. output power |
|---|---|---|---|---|---|
| PFE300SA-12 | 85-265VAC (50-60Hz) |
3.8A | 12VDC | 25A | 300W |
| 1.9A | |||||
| PFE300SA-28 | 85-265VAC (50-60Hz) |
3.7A | 28VDC | 10.8A | 302.4W |
| 1.8A | |||||
| PFE300SA-48 | 85-265VAC (50-60Hz) |
3.6A | 48VDC | 6.3A | 302.4W |
| 1.8A | |||||
| PFE500SA-12 | 85 - 265VAC (50 - 60Hz) |
4.9A | 12VDC | 33A | 396W |
| 2.4A | |||||
| PFE500SA-28 | 85 - 265VAC (50 - 60Hz) |
6.0A | 28VDC | 18A | 504W |
| 2.9A | |||||
| PFE500SA-48 | 85 - 265VAC (50 - 60Hz) |
5.9A | 48VDC | 10.5A | 504W |
| 2.9A | |||||
| PFE700SA-48 | 85～265VAC (50～60Hz) |
8.0A | 51VDC | 14A | 714W |
TDK lambda Vietnam, PFE500SA-12 TDK lambda, Đại lý TDK lambda
